TUNNEL TANK FIRE CISTERNS AVAILABLE IN ANY SIZE by adding additional pieces.

This example is presented using our 30,000-gallon fire cistern specifications; however, it can be adjusted for different tank specifications based on project requirements.
30,000 Full Size Engineered Plan
Piping shown is as proposed.  The Town Fire Department must approve the cistern and may require different and/or additional piping requirements and placement.

The following are samples of standard units we have produced. Any size can be obtained in our Tunnel Tank Fire Cistern by adding additional pieces.

• 10,000 Fire Cistern

• 15,000 Fire Cistern

• 20,000 Fire Cistern

• 25,000 Fire Cistern

• 27,500 Fire Cistern

• 30,000 Fire Cistern

• 37,500 Fire Cistern

• 40,000 Fire Cistern

• 45,000 Fire Cistern

• 50,000 Fire Cistern

• 52,500 Fire Cistern

• 55,000 Fire Cistern

• 60,000 Fire Cistern

• 2 Connected 30,000 Gallon Fire Cisterns - Total 60,000 Tank

• Fire Cistern with SUMP
